DTM 352 Total Station Battery Charger Nimh Battery Charger

Place of Origin China
Brand Name Nikon
Certification ISO
Model Number Q-75E
Minimum Order Quantity 5 Pieces
Price 40USD~50USD
Packaging Details Box and Carton
Delivery Time 3-5 work day
Payment Terms T/T
Supply Ability 500pcs per month
Product Details
Model Q-75E Color Black
Used For Nikon Total Station Weight 410g
Warranty 1 Year Certificate CE
Charger Adapter US/EU/UK/AU/PLUG Adapter Input 100~240VAC 50-60Hz
Ouput 1.8A Charging Time 3 Hours
Size 190*135*57 Mm Condition New
High Light

NIMH Total Station Battery Charger


DTM 352 Total Station Battery Charger


DTM 352 nimh battery charger

Leave a Message
Product Description

Nikon DTM NI-MH Charger Q-75E for BC-65 BC-80 Battery Total Station DTM 352


Model: Q-75E



Model Q-75E
Color Black
Used For Nikon Total Station
Input 100~240VAC 50-60Hz
Output 1.8A
Temperature 10-40 centigrate
Weight 410g
Size 190*135*57 mm
Charger Adapter: US/EU/UK/AU/PLUG adapter
Warranty 1 year
Package OPP+bubble bagouter packing
Charging Time 3 Hours
For Battery Trimble M3 Battery, Nikon BC-65 BC-80 Battery
Fits DTM-831E, DTM-851, DTM-800, DTM-531E, DTM-530, DTM-532, DTM-552, DTM-632



Brand new charger for the following NK batteries: BC-50, BC-60, BC-65, BC-70, BC-80 batteries



Charger takes about three hours to charge a battery
AC input: 100V – 240V 0.3A 50/60Hz
Output: DC 1.8A
Usable temperature : 0-40 degree
Charger plug is EUR plug


Charging the batteries

New and stored batteries

New NiCd and NiMH batteries reach their maximum capacity only after a few charging and discharging cycles. The batteries should be fully discharged and charged three to five times. NiMH batteries that have been stored and not used for an extended period (more than a month) should be refreshed simularly. For Li-Ion batteries, a single discharging and charging cycle is sufficient. The easiest way to perform this cycling is by using the GKL221 Charging Station which has a discharge function. Alternatively, the batteries can be charged and then placed in the related survey equipment during normal use and discharged until the equipment switches off.


Batteries in regular use

After use the battery can be placed in the charger until fully charged (the green light flashes). The charging time depends on the battery capacity and temperature.


Charging temperature

The charging temperature (ambient temperature) has a significant impact on the life of the batteries. Charging at high temperature can cause loss of capacity. These losses in capacity are irreversible. Even with several charging and discharging cycles, the original capacity can no longer be obtained. For optimal charging, we recommend that the batteries be charged at ambient temperatures as low as possible (+10 °C to +20 °C / +50 °F to +68 °F). The permitted temperature range in which charging can still be performed is between 0 °C and +35 °C (+32 °F and +95 °F).
