GEB171 Total Station Batteries 10000mAh Lithium Ion Rechargeable Battery

Place of Origin China
Brand Name Leica
Certification ISO CE
Model Number GEB171
Minimum Order Quantity 5 Pieces
Price 100USD~150USD
Packaging Details 1pc per box
Delivery Time 3-5 work day
Payment Terms T/T
Supply Ability 500pcs per month
Product Details
Cell Type Ni-Mh Voltage 12V
Weight 2300g Size 255*103*77mm
Capacity 10000mAh Charger GKL22
Color Red Condition New
High Light

GEB171 Total Station Batteries

,

10000mAh Total Station Batteries

,

GEB171 Lithium Ion Rechargeable Battery

Leave a Message
Product Description

Leica Battery External Rechargeable Battery GEB171 12V 10000mAh for Leica Total Station TPS1000,TCA1800,TC2005



Model: GEB171



Specifications:

Voltage 12V
Weight 2300g
Size 255*103*77mm
Type Ni-Mh
Capacity 10000mAh
Package Individual Box Package
Warranty 1 Year
Charger GKL22
Used For Leica Total Stations



Used For Instruments:

TPS100 TCA1800 TC2003 TPS100 TCA1800 TC2005 Series Total Station





Storage

Leica Geosystems batteries can be stored at –40 °C to +55 °C (–40 °F to +131 °F). Do not store batteries inside the surveying instrument. After storage, charge the battery fully before use. NiCd NiCd batteries can be stored for an unlimited period in any state of charge. NiMH NiMH batteries must always be stored fully charged and recharged after 180 days at the latest. High temperatures and high atmospheric humidity accelerate self-discharging. We recommend storage in the range from 0 °C to +20 °C (+32 °F to +68 °F) in a dry environment. If NiMH batteries are stored in the discharged state for an extended period irreversible damage can be caused. Li-Ion Li-Ion batteries start to deteriorate from manufacture. To reduce the aging effect, store the battery in a cool place at 10%–50% state-of-charge. Li-Ion batteries do not require regular charging while in storage.



Memory effect

The «Memory Effect» occurs if the same charging and discharging (partial discharge) conditions are continuously applied to a battery. The battery then no longer provides the full capacity. The operating time per battery charge reduces. If the capacity of the battery drops noticeably, it is recommended to subject the battery to the refresh function 2 to 3 times (see Section 2.9). The memory effect occurs particularly with NiCd batteries. With NiMH batteries the memory effect is not so pronounced. Li-Ion batteries are not influenced by the memory effect.



Battery refresh function

If the capacity of a NiCd or NiMH battery drops noticeably, the battery can be refreshed using two to three full charge and discharge cycles. The GKL221 Charging Station has a discharging and charging function for refreshing batteries. Since GKL112 and GKL211 do not have a discharge function the batteries are to be discharged in the instrument (i.e. operate until the instrument switches off).
