6000mAh Geb Battery External TPS100 NiMH Rechargeable Battery

GEB70 120V 6000mAh GEB External NiMH Battery for Leica TPS100 TCA1800 TC2003 TPS100 TCA1800 TC2004 Total Stations

Model: GEB70

Specifications:

Highlights:

• Capacity: 6,000 mAh
• Power: 12 V
• Charges up to 4 or 5 hours
• Plugin battery
• Storage temperature: -4 °F to 95 °F
• Works with many Leica total stations

Introduction:

The GEB External NiMH Battery for Leica Total Stations is a plugin battery that is designed to work with many Leica total stations such as the TPS100, TCA1800, TC2003TPS100, TCA1800, TCA2004 (GEB70 only), and TCA2005 (GEB171 only). This NiMH rechargeable battery has a large 6,000 mAh (milliampere hour) capacity and a 12-volt power which charges up to four or five hours. It comes with a compact size of 255*103*77mm and has a storage temperature of -4 °F to 95 °F (-20 °C to 35 °C).

Used For Instruments:

TPS100 TCA1800 TC2003 TPS100 TCA1800 TC2005

Battery Life

The life of batteries is primarily defined by the following factors: • Electrical loading • Charging method • Temperatures on charging, discharging and storage • Quality of the cells Losses in capacity caused by incorrect charging are practically excluded with the Leica Geosystems chargers which have special switch off criteria to protect the battery. Reduction in battery capacity is normally due to age. However it can also be the result of storage at excessively low or high temperatures (see Section 2.6). The suppliers who provide batteries to Leica Geosystems are among the leading manufacturers of batteries and guarantee good quality.

Protecting the environment/disposal

For reasons of environmental protection and safety, used or defective batteries must not be thrown away. They must be correctly disposed of in a discharged state. Follow the national regulations on disposal.

Safety/precautionary measures

For the safe usage of batteries, please refer to the section on safety in the User Manual supplied with the products.
